1.  Reduce training time, lower the risk of employee operation, and less skilful requirement for the taping edge operators.

2.  Automated transfer table and mattress turn over arm enable the operator working in one position without moving around.

3.  When ready to sew the opposite side, turn over arm unit flip the mattress automatically.

4.  Intelligent design, increase productivity for high-quality mattress.

5.  Fixed operation position, operator focus on quality rather than  turning the operation table.

6.  Variable speed drive, automatically slow down on turning corner.

7.  Machine head height and inclination are adjustable.

8.  Unique design, automatic turning and flipping the mattress.

9.  Equipped 300UB5 machine head or Pfaff sewing head

10.  Sewing speed: 2800RPM

11.  Min & Max Sewing Height: 50 - 350MM

12.  Output: 16-20 pcs/hour

13.  Anti-static conveyor belt.

14.  Adjustable corner radius for smoothly running when turning corner.

15.  Fully automatic parameters on turning corner system reducing operator-tired feeling.

16.  Work table size: 3750MM*2050MM.
